Type 5 Weld & Cutting Set

The G-Tech Type 5 Welding & Cutting Set is a complete industrial-grade oxy-fuel kit, built to meet the high-performance demands of fabricators, engineers, and site maintenance teams. Designed with Type 5 (EN560) quick-action connections, this kit allows you to swiftly switch between welding, cutting, and heating using the same handle and mixer maximising efficiency without compromising on safety or durability.

Whether you’re performing structural fabrication, on-site cutting, or workshop brazing, this set delivers reliable results in even the most demanding environments.

Set Contents and Specifications:

• Single Stage 2-Gauge Oxygen Regulator – 300 Bar Inlet Pressure
  • Outlet pressure range: 0–10 bar
  • Twin gauge design for cylinder and outlet pressure monitoring
  • Heavy-duty brass body with high-accuracy control knob
  • Safety pressure relief valve included
• Single Stage 2-Gauge Acetylene Regulator – 25 Bar Inlet Pressure
  • Outlet pressure range: 0–1.5 bar
  • Dual gauge configuration for clear inlet/outlet readings
  • Precision regulator for low-pressure acetylene supply
  • Flame-stabilising design with sintered filter
• In-Line Flashback Arrestors (Oxygen & Fuel Gas)
  • Compliant with EN 730 / ISO 5175 safety standards
  • Built-in thermal shut-off and flame arrestor
  • Designed for high flow with secure non-return functionality
• Gas Hoses
  • 8mm ID twin hose set, 5 metres each
    • Blue hose (Oxygen): Fitted with 3/8” BSP check valve
    • Red hose (Acetylene): Fitted with 3/8” BSP check valve
  • Manufactured to BS EN ISO 3821
• Type 5 Torch System
  • Shank, Cutting Attachment & Welding Mixer
    • Heavy-duty Type 5 compatible design
    • Nozzle-mix cutting and welding torch for maximum flame stability
    • Ergonomic handle with responsive valve controls
• Swaged Welding Nozzles
  • No. 5 & No. 7: Suitable for medium to heavy-duty welding and brazing
  • Tapered design ensures efficient gas flow and precise flame control
• ANM Cutting Nozzles
  • Size: 1/32” & 3/64”
  • For use with oxygen-acetylene cutting attachment
  • Designed for clean cuts on mild steel up to approx. 75 mm (depending on nozzle and conditions)
• Accessories
  • Metal Box Tip Cleaner: Multiple reamers for maintaining nozzle performance
  • Single Flint Lighter: Steel frame with replaceable flint for reliable ignition
  • Combination Spanner: Multi-size tool for fitting adjustments and hose connections
  • Stainless Steel Tool Case: Durable, corrosion-resistant case for secure storage and transport

Applications:

• Oxy-acetylene cutting and welding of steel and ferrous metals
• Suitable for fabrication, shipbuilding, structural work, demolition, and heavy repairs

This kit can also be used for cutting with propane gas by fitting appropriate propane nozzles (PNM) and mixer, Type 5 propane bent necks, and heating nozzles.

Compliance:
Meets or exceeds relevant UK and EU standards for gas welding and cutting equipment.
